SLDL231T
Prismatic
40º 55º

  • timeless modern design, recessed for low glare
  • general all purpose luminaire
  • fully adjustable 360° gimbal
  • suitable for indoor use and exterior under soffits
  • IP65 front
  • constant current
  • compatible with SLiC Luminaire Controllers and Push Button Controllers for Casambi-enabled lighting automation
  • CCT Options: 2400K, 2700K, 3000K, 4000K, Sunset Dimming and Tunable White.
    • Tunable White enables CCT choice (4000 – 1800K) at any intensity. Perfect for Circadian Rhythm healthy lighting and other lighting automation scenes.
    • Tunable White works with SLiC Luminaire Controllers or Dali drivers in lighting automation systems.

Define Your Product

Select the options below to define your product
Please select one option from each line.
Options will remain to enable product selection.
All lines must be selected to show a product.

Clear

Light Level and Beam Generator


Selected product: SLDL231T
Prismatic
40º 55º

Product Code: N/A

Add to My Products List
Beam Angle

40°, 55°

Diffuser

Prismatic

Colour Temperature

2400K, Tunable white, 2700K, 3000K, 4000K, Sunset Dimming

CRI

95, 90, 97

Trim Colour

Textured White, Textured Black

Driver Type

SLiC Casambi, Phase-Cut Dimming Driver, Dali Dimming Driver

Driver Current

100mA, 150mA, 180mA, 220mA, 230mA, 260mA, 300mA

ZELA Tilt 2 Spec Sheet.pdf SDOC-SL1025-ZELA-SLDL2-Non-Fire-Rated-1.pdf ZELA Tilt 2 Lookup Table
